StarTech.com POEINJ4G
StarTech.com POEINJ4G. Cabling technology: 10/100/1000Base-T(X) Network standard: IEEE 802.3 IEEE 802.3ab IEEE 802.3af IEEE 802.3at IEEE 802.3u. AC input voltage: 100-240V Power consumption (max): 120W Output voltage: 52V. Width: 2.76" (7 cm) Depth: 3.82" (9.7 cm) Height: 1.02" (2.6 cm). Mean time between failures (MTBF): 50000h. Package width: 8.43" (21.4 cm) Package depth: 10" (25.5 cm) Package height: 2.56" (6.5 cm)
| $180.00 |
Manufacturer:
STARTECH.COM
Item:
POEINJ4G
Our Part #
POEINJ4G
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $9.00 |
$180.00EA
Availability
In Stock
Product description
Deliver power and data to four Power over Ethernet devices using this wall-mountable PoE+ midspan hub
This Gigabit midspan PoE+ injector is a cost-effective alternative to upgrading your existing network switch to a PoE-capable model.
It supplies up to 30 Watts output to each port so you can easily power and access up to four high-power PoE-compliant devices � such as IP cameras � using standard Ethernet cable.
More power with less cost and hassle
This versatile midspan PoE+ injector is suited for almost all PoE device classes including wireless access points as well as IP phones and cameras. The high-power PoE+ injector offers 120W total power distribution and delivers full power � up to 30.8W � from each port. Now you can easily scale and power your PoE+ devices across long distances even in remote locations where a typical power outlet is unavailable.
Plus the cost-effective Power over Ethernet+ injector lets you connect your PoE-powered devices (PDs) to a non-PoE-capable switch avoiding the expense and aggravation of upgrading your existing switch to a PoE-enabled model.
Easy to set up in mixed environments
This injector�is the perfect solution for a variety of environments. It features a wall-mountable rugged metal casing but is palm-sized making it perfect for desktop placement too.
With plug-and-play operation you can enjoy fast and hassle-free setup without disrupting your workflow.
Convenient protected connections
Not sure which class your PoE devices are? The Gigabit midspan PoE+ injector�automatically detects the power requirements of your PoE PDs and delivers the appropriate level of power without damaging your devices.
With integrated circuit protection between each port your devices are also protected from power interference.
The POEINJ4G is backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Easily connect power and operate up to four Gigabit PoE-powered devices (PD)
- Delivers full power to each port � up to 30.8 watts (802.3at) or 15.4 watts (802.3af) to each connected device
- Flexible setup with a desktop-sized or wall-mountable metal housing
Specifications
AC adapter bundled
Y
AC input voltage
100-240
Auto MDIX IEEE
Y
Auto-negotiation
Y
Cables included
AC
Cabling technology
10/100/1000Base-T(X)
Certification
CE FCC
Color of product
Black
Data transfer rate
2000
Depth
97
Full duplex
Y
Height
26
Housing material
Steel
LED indicators
PoE Power
Manual
Y
Maximum transfer distance
100
Mean time between failures (MTBF)
50000
Network standard
IEEE 802.3 IEEE 802.3ab IEEE 802.3af IEEE 802.3at IEEE 802.3u
Operating relative humidity range
5 - 95
Operating temperature range (T-T)
0 - 50
Output current
2.31
Output voltage
52
Package depth
255
Package height
65
Package weight
1400
Package width
214
Plug type
Type M
Power consumption (max)
120
Power over Ethernet (PoE) support
Y
RoHS compliance
Y
Storage temperature range (T-T)
-10 - 70
Weight
220
Width
70
