Intellinet IDC-752IR

The Intellinet IDC-752IR Megapixel Night-Vision Network Dome Camera is designed for indoor day and night security surveillance and comes fully equipped with state-of-the-art features that set it apart from other network cameras on the market today.

Megapixel Resolution for Excellent Video Quality

The IDC-752IR Network Dome Camera is equipped with a 1-megapixel sensor that generates crystal-clear images up to 1280 x 720 pixels for much more detailed and realistic video. Thanks to progressive-scan image technology the jagged lines caused by conventional interlacing image sensors (sometimes seen as a flickering effect on moving objects) have been all but eliminated.

Multi-Streaming: Simultaneous H.264 + MPEG4 + 3GPP + Motion-JPEG

The Intellinet IDC-752IR Network Dome Camera provides outstanding video quality while consuming less network bandwidth thanks to integrated H.264 video compression. The IDC-752IR Network Dome Camera also supports MPEG4 and Motion-JPEG video formats as well as 3GPP mobile phone streaming for easy on-the-road connectivity with your compatible smartphone.

Surveillance 24 Hours a Day Even in Complete Darkness

Equipped with 18 powerful IR LEDs the IDC-752IR turns night into day. Thanks to its removable IR cut filter (ICR) and its IR-corrected varifocal megapixel lens the camera sends true-color video during the day and crystal-clear black and white footage at night. The user can adjust the threshold and allow the camera to automatically switch between day and night mode or use the camera's integrated internal scheduler. The camera also supports third-party IR illuminators (850 nm) allowing for surveillance of larger areas during nighttime hours.

WDR Enhanced Video Surveillance

WDR stands for Wide Dynamic Range and allows the Intellinet network dome cameras to capture video in areas with high contrasting objects; e.g. extremely bright and extremely dark. In a normal camera if an object in a darker area of the image frame is next to a bright area � for example a person in a shadow is next to an area with bright sunlight � then the person in the shadow would be very dark to the point of becoming indistinguishable from the background. The human eye by contrast can handle these differences much better. With WDR the dynamic range of the camera is greatly enhanced. As a result you can now clearly see the person in the shadow while the rest of the frame is still correctly exposed just as if it was seen through the human eye.

Power over Ethernet

The Intellinet IDC-752IR Megapixel Night-Vision Network Dome Camera supports the IEEE 802.3af standard allowing it to be installed in locations where an AC power source is not readily available. Simply plug the camera into a PoE-compliant switch or injector and begin transmitting power as well as data over the Cat5e or Cat6 network cabling. The camera's low power usage of just 5.5 watts allows it to be operated with regular IEEE 802.3af-compliant PoE injector.

Video Storage

The IDC-752IR is equipped with an internal MicroSD/SDHC memory card slot allowing the camera to store videos and images even if a connection to the NVR is down. In addition video can be submitted via e-mail uploaded to an FTP server or stored directly on a shared network drive (NAS Samba/CIFS/SMB share).

SSL Encryption

The Intellinet IDC-752IR Network Dome Camera offers a secure network connection via data encryption between the camera and the network client.
