Intellinet 530378 Network Switch
Intellinet 530378. Basic switching RJ-45 Ethernet ports quantity: 5 8 5. Network standard: IEEE 802.3 IEEE 802.3ab IEEE 802.3u IEEE 802.3x. MAC address table: 1024 entries Supported data transfer rates: 10/100/1000 Mbps Maximum data transfer rate: 1 Gbit/s. Data link protocols: Ethernet Fast Ethernet Gigabit Ethernet 10 Gigabit Ethernet. Color of product: Black Certification: FCC CE
| $32.72 |
Manufacturer:
Intellinet
Item:
530378
Our Part #
530378
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $1.64 |
$32.72EA
Availability
In Stock
Product description
The INTELLINET NETWORK SOLUTIONS Gigabit Ethernet Desktop Switch is perfect for the home or small office delivering top speeds to the desktop to satisfy your demanding network needs.
High-Speed Performance
This desktop switch includes five Gigabit Ethernet ports providing you with high performance on your network to handle quick transfer speeds to support disk mirroring data backup graphics image file transfers and other bandwidth-intensive applications.
Auto Features
This network LAN switch includes many auto features that make it easy to use. No configuration is required making installation Plug and Play and hassle free. And Auto-MDI/MDI-X crossover on all ports eliminates the need for any crossover cables. Each of the five ports on this network LAN switch automatically senses the link speed of the connected network device and adjusts to 10 100 or 1000 Mbps for compatibility and maximum performance.
Reliable Operation
The Gigabit Ethernet Desktop Switch supports flow control when operating in half duplex mode and supports IEEE 802.3ab in full duplex mode ensuring that your data transfer and network connectivity continue to run smoothly and uninterrupted. This in conjunction with the broadcast storm control and the store and forward switching method further ensure that your connections remain active even under extremely busy conditions.
Specifications
10G support
N
Auto MDI/MDI-X
Y
Basic switching RJ-45 Ethernet ports quantity
5 8 5
Certification
FCC CE
Color of product
Black
Connectivity LEDs
Y
Data link protocols
Ethernet Fast Ethernet Gigabit Ethernet 10 Gigabit Ethernet
DC-in jack
Y
Dimensions (W x D x H)
5.1 x 3 x 1
Dimensions (WxDxH)
130 x 77 x 25
Flow control support
Y
Full duplex
Y
Input current
0.8
Input voltage
7.5
Jumbo Frames support
Y
MAC address filtering
Y
MAC address table
1024
Maximum data transfer rate
1
Network cabling
Cat3 4 5 5e UTP/STP
Network standard
IEEE 802.3 IEEE 802.3ab IEEE 802.3u IEEE 802.3x
Networking features
Gigabit Ethernet
Operating relative humidity range
10 - 90
Operating temperature range (T-T)
32 - 131
Operating temperature range (T-T)
0 - 55
Packet buffer memory
0.112
Power consumption (typical)
10
Power supply type
DC
Stackable
N
Storage temperature range (T-T)
-20 - 90
Store-and-forward
Y
Supported data transfer rates
10/100/1000 Mbps
Weight
0.6
Weight
280
Wireless technologies
Wired
