Cisco Catalyst 2960C
Cisco Catalyst 2960C. Switch layer: L2 Switch type: Managed. Copper ethernet cabling technology: 1000BASE-T 100BASE-TX 10BASE-T. MAC address table: 4000 entries Supported data transfer rates: 10/100/1000 Mbps Maximum data transfer rate: 13.2 Gbit/s. Fiber ethernet cabling technology: 1000BASE-LH 1000BASE-LX 1000BASE-SX 1000BASE-ZX 100BASE-BX 100BASE-FX 100BASE-LX Fiber type: Multi-mode Fiber optic connector: LC. Management protocols: IPv4 IPv6 MLD v1/v2 SNMP v3 Switching protocols: IPv6
| $984.11 |
Manufacturer:
CISCO
Item:
WS-C2960CG-8TC-L
Our Part #
WS-C2960CG-8TC-L
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $49.21 |
$984.11EA
Availability
In Stock
Product description
The Cisco� Catalyst� 3560-C and 2960-C Series Compact Switches are small form-factor Fast Ethernet and Gigabit Ethernet switches designed for deployments outside the wiring closet. Enterprise and commercial customers can deliver advanced security services unified communications wireless IP video cameras and other applications for the office workspace micro branch office classroom cruise ship and other wiring-constrained environments.
The Cisco Catalyst 3560-C and 2960-C series compact switches are shown in Figure 1.
Cisco Catalyst 3560-C and 2960-C Series highlights:
- PoE pass-through. An innovative feature and industry first for passing power from the compact switch to end devices.
- Media Access Control Security (MACsec) hardware-based encryption.
- Power over Ethernet Plus (PoE+) up to 30 W per port.
- USB and Console port for file backup distribution and simplified operations.
- Fanless for silent operation.
- Enhanced limited lifetime hardware warranty (E-LLW) with next business day (NBD) advance hardware replacement and 90 day access to Cisco Technical Assistance Center (TAC) support.
Specifications
10G support
N
Access Control List (ACL)
Y
Auto MDI/MDI-X
Y
Bandwidth
10
Basic switching RJ-45 Ethernet ports quantity
11
Broadcast storm control
Y
Certification
FCC 15 CFR 47 A EN 55022 (CISPR22) EN 55024 (CISPR24) CE marking AS/NZS A CISPR22:2004 EN55022 VCCI A V-3/2007.04 KCC A KN24/KN22 ANATEL CCC GOST RoHs 6 CLEI
Copper ethernet cabling technology
1000BASE-T 100BASE-TX 10BASE-T
DHCP client
Y
DHCP server
Y
Dimensions (W x D x H)
10.6 x 8.4 x 1.74
Dimensions (WxDxH)
269 x 213 x 44.4
Fiber ethernet cabling technology
1000BASE-LH 1000BASE-LX 1000BASE-SX 1000BASE-ZX 100BASE-BX 100BASE-FX 100BASE-LX
Fiber optic connector
LC
Fiber type
Multi-mode
Flash memory
64
Heat dissipation
60
IGMP snooping
Y
Input current
0.3 - 0.15
Input frequency
50/60
Input voltage
100 - 240
Internal memory
128
IP routing
Y
Jumbo Frames support
Y
LED indicators
Y
Link aggregation
Y
MAC address filtering
Y
MAC address table
4000
Management protocols
IPv4 IPv6 MLD v1/v2 SNMP v3
Maximum data transfer rate
13.2
Mean time between failures (MTBF)
542482
Multicast support
Y
Networking features
Gigabit Ethernet
Non-operating altitude
0 - 4000
Number of VLANs
255
Operating altitude
0 - 3048
Operating relative humidity range
5 - 95
Operating temperature range (T-T)
23 - 104
Operating temperature range (T-T)
-5 - 40
Power consumption (typical)
18
Power LED
Y
Power over Ethernet (PoE) support
N
Quality of Service (QoS) support
Y
Rate limiting
Y
Safety
UL 60950-1 CAN/CSA 22.2 No. 60950-1 EN 60950-1 IEC 60950-1 GB 4943 IEC 60825
Spanning tree protocol
Y
SSH/SSL support
Y
Stackable
Y
Storage relative humidity range
5 - 95
Storage temperature range (T-T)
-25 - 70
Supported data transfer rates
10/100/1000 Mbps
Switch layer
L2
Switch Type
Managed
Switching protocols
IPv6
Wavelength
1610
Weight
3.0
Weight
1350
Wireless technologies
Wired
