APC Service Bypass Panel- 100-120V
APC Service Bypass Panel- 100-120V. Color of product: Black. Input frequency: 50/60 Hz Load capacity: 3000 VA Maximum input current per phase: 24A. Input connection type: NEMA L5-30P Output connections: 6x NEMA 5-15R 2x NEMA 5-20R. Cable length: 120.1" (3.05m). Dimensions (WxDxH): 17 x 25.5 x 3.5" (432 x 648 x 89 mm) Weight: 481.1 oz (13.64 kg) Package dimensions (WxDxH): 24 x 39 x 7.99" (610 x 991 x 203 mm)
| $544.58 |
Manufacturer:
AMERICAN POWER CONVERSION
Item:
SBP3000RM2U
Our Part #
SBP3000RM2U
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $27.23 |
$544.58EA
Availability
In Stock
Product description
19 inch Rack-Mountable
Supplies redundant AC power to connected equipment. Two AC lines power the unit and if the primary AC power fails the unit will automatically switch to the alternate power source.
Quick Transfer Rate
Transfer rate is within the industry standard and within the time power supplies will typically drop loads. The transfer of one power source to another is seamless to the connected equipment avoiding disruption of equipment performance.
Wrap Around System Bypass
(3) Breaker maintenance bypass panel to isolate the UPS from the critical load
Meets UL Requirements
Specifications
Cable length
3.05
Certification
CSA EN 60950 GOST IEC 60950 IEC 60950 UL 1778
Color of product
Black
Dimensions (WxDxH)
432 x 648 x 89
Input connection type
NEMA L5-30P
Input frequency
50/60
Load capacity
3000
Maximum input current per phase
24
Maximum total current draw per phase
30
Operating relative humidity range
0 - 95
Operating temperature range (T-T)
-20 - 50
Output connections
6x NEMA 5-15R
2x NEMA 5-20R
2x NEMA 5-20R
Package dimensions (WxDxH)
610 x 991 x 203
Package weight
24560
Storage relative humidity range
0 - 95
Storage temperature range (T-T)
-25 - 65
Weight
13640
