StarTech.com POEEXT1GAT
StarTech.com POEEXT1GAT. Cabling technology: 10/100/1000Base-T(X) Network standard: IEEE 802.3 IEEE 802.3ab IEEE 802.3af IEEE 802.3at IEEE 802.3u. Power consumption (max): 3.2W. Width: 2.72" (6.9 cm) Depth: 3.7" (9.4 cm) Height: 0.984" (2.5 cm). Mean time between failures (MTBF): 50000h. Package width: 5.28" (13.4 cm) Package depth: 7.99" (20.3 cm) Package height: 2.64" (6.7 cm)
| $146.48 |
Manufacturer:
STARTECH.COM
Item:
POEEXT1GAT
Our Part #
POEEXT1GAT
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $7.32 |
$146.48EA
Availability
In Stock
Product description
This Gigabit PoE+ extender spans your Power over Ethernet (PoE) device over longer distances letting you double the 100m limitations of a traditional PoE infrastructure.
Now you can connect your Gigabit PoE device up to a maximum of 200m away so it�s easy to install a remote IP camera or access point. Plus the extender can be daisy-chained for more scalability.
Unrestricted PoE+ range and convenience
Need more distance? This convenient PoE+ repeater maximizes range and flexibility by extending your PoE connection by an extra 100m (330ft) while providing 24-watt power output to compatible devices.
Simply connect the extender to your power sourcing equipment (PSE) and your PoE-powered device (PD) and you�re all set. The extender is compliant with the 802.3at/af standard so it will work with existing PSE such as a StarTech.com PoE+ injector (POEINJ1G) or PoE+ switch (IES81000POE).
Daisy chain for longer distance and flexibility
Still need more distance? If an extra 100m isn�t enough this full-featured PoE extender offers daisy chain capability.
You can easily connect four extenders together letting you install your PoE+ PD up to 500m (1640ft) away. It�s perfect for business education and retail environments (output wattage is dependent on the number of daisy-chained extenders used).
Convenient installation options and durable construction
Get up and running quickly. This Gigabit PoE+ extender can be positioned right where you need it with a wall-mountable design that requires no external power adapter.
You can enjoy reliable performance with little worry of downtime or failure the extender features a rugged metal housing with built-in ESD and surge protection.
The POEEXT1GAT is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Specifications
Auto MDIX IEEE
Y
Auto-negotiation
Y
Cabling technology
10/100/1000Base-T(X)
Certification
CE FCC
Color of product
Black
Data transfer rate
2000
Depth
94
Full duplex
Y
Height
25
Housing material
Steel
Jumbo Frames support
N
LED indicators
Activity Link PoE
Manual
Y
Maximum transfer distance
100
Mean time between failures (MTBF)
50000
Network standard
IEEE 802.3 IEEE 802.3ab IEEE 802.3af IEEE 802.3at IEEE 802.3u
Operating relative humidity range
5 - 95
Operating temperature range (T-T)
0 - 50
Package depth
203
Package height
67
Package weight
339
Package width
134
Power consumption (max)
3.2
Power over Ethernet (PoE) ports quantity
2
Power over Ethernet (PoE) support
Y
RoHS compliance
Y
Storage temperature range (T-T)
-10 - 85
Type
Repeater
Weight
188
Width
69
