Microsemi PD-9001GR
Microsemi PD-9001GR. Power over Ethernet (PoE): 55V. Dimensions (WxDxH): 2.17 x 1.28 x 5.51" (55 x 32.5 x 140 mm) Weight: 7.05 oz (200g). AC adapter input voltage: 100 - 240V AC adapter frequency: 50/60 Hz. Certification: FCC RoHS WEEE CE UL/cUL
| $87.41 |
Manufacturer:
MICROSEMI POE
Item:
PD-9001GR/AC
Our Part #
PD-9001GR/AC
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $4.37 |
$87.41EA
Availability
In Stock
Product description
Single port Gigabit Midspan 30W
PD9001GRThe PowerDsine 9001GR is a single port solution for remote powering of high power edge devices requiring up to 30W of scalable power-over-Ethernet.
The IEEE 802.at standard PD 9001GR PoE midspan was recently upgraded to a smaller form factor but still comes with the industry leading PowerDsine PoE technology that enables 30W of PoE over standard Cat5 or better cables to easily upgrade IP surveillance devices WLAN APs and other Ethernet devices. This plug and play device allows easy installation and placement in hard-to-reach places. Combined with a PoE extender Ethernet devices can easily be powered more than 100M away from network room at gigabit data transfer rates.
Specifications
AC adapter frequency
50/60
AC adapter input voltage
100 - 240
Certification
FCC RoHS WEEE CE UL/cUL
Compliance industry standards
IEEE 802.3at
Dimensions (WxDxH)
55 x 32.5 x 140
Ethernet interface type
Gigabit
Ethernet LAN (RJ-45) ports quantity
2
Ethernet LAN data rates
10 100 1000
Input current
0.8
Input frequency
50 - 60
Input voltage
100 - 240
LED indicators
Y
Operating relative humidity range
0 - 90
Operating temperature range (T-T)
-10 - 40
Operating temperature range (T-T)
-4 - 104
Power consumption (typical)
36
Power over Ethernet (PoE)
55
Power over Ethernet (PoE) support
Y
Storage relative humidity range
0 - 95
Storage temperature range (T-T)
-20 - 70
Weight
200
