Microsemi PowerDsine 6506G
Microsemi PowerDsine 6506G. Supported data transfer rates: 10/100/1000 Mbps Maximum data transfer rate: 1 Gbit/s. Color of product: Silver Safety: UL/cUL Per EN 60950 GS Mark Per EN 60950. Mean time between failures (MTBF): 100000h. Power consumption (typical): 100W Input voltage: 90 - 264V. Dimensions (WxDxH): 17.2 x 10.7 x 1.73" (438 x 272 x 44 mm) Wireless technologies: Wired Input frequency: 47/63 Hz
| $549.17 |
Manufacturer:
MICROSEMI POE
Item:
PD-6506G/AC/M
Our Part #
PD-6506G/AC/M
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $27.46 |
$549.17EA
Availability
In Stock
Product description
The PowerDsine 6500/6500G series sets a new standard for highly secure remotely-managed and safe-to-use Power over Ethernet Midspans (PoE injectors).
PowerDsine 6500/6500G series comprises 6 12 and 24- port models making an even wider range of flexible Power over Ethernet installations possible.
PowerDsine 6500/6500G family allows IP telephones wireless LAN access points security network cameras and many other types of data terminals to receive power along with data over standard Ethernet cables leaving network infrastructure completely unaltered. With PoE data and power flow smoothly and safely over a single LAN cable with no interference.
A PoE Midspan (PoE injector) resides between the Ethernet switch and the data terminals delivering data along with power from switch to powered devices. It is a highly effective means for injecting power into LAN cables.
With support for SNMP 6500/6500G series Midspans offer the most advanced and highly secure network management options enabling full control over all Midspan operation aspects.
PowerDsine 6500/6500G series Midspans which fully comply with the IEEE 802.3af PoE definition standard provide a minimum of 15.4 Watts of power through each port and ensure safe operation of any standard PoE data terminal.
Specifications
10G support
N
Basic switching RJ-45 Ethernet ports quantity
6
Color of product
Silver
Dimensions (WxDxH)
438 x 272 x 44
Input frequency
47/63
Input voltage
90 - 264
Maximum data transfer rate
1
Mean time between failures (MTBF)
100000
Operating relative humidity range
10 - 90
Operating temperature range (T-T)
0 - 40
Power consumption (typical)
100
Power over Ethernet (PoE) support
Y
Safety
UL/cUL Per EN 60950 GS Mark Per EN 60950
Storage relative humidity range
5 - 95
Storage temperature range (T-T)
-20 - 70
Supported data transfer rates
10/100/1000 Mbps
Wireless technologies
Wired
