Tripp Lite OMNIVS1500XL Uninterruptible Power Supply (UPS)

Tripp Lite OMNIVS1500XL. Output power capacity (VA): 1500 VA Output power: 940W Input operation voltage (min): 75V. AC outlet types: NEMA 5�15R Power plug: NEMA 5-15P Cable length: 70.9" (1.8m). Battery recharge time: 4.5h Typical backup time at half load: 13 min Typical backup time at full load: 4.5 min. Form factor: Tower Color of product: Black Material: Polycarbonate. UPS topology: Line-Interactive Waveform: Sine Cooling type: Active
$307.60
Manufacturer:
Tripp Lite
Item:
OMNIVS1500XL
Our Part #
OMNIVS1500XL
Condition
New
Extended Warrenty
1 Year Extended Warrenty$15.38
$307.60EA
Availability In Stock
Great Deals Everyday

You may be also interested

Product description

Tripp Lite's OMNIVS1500XL line interactive UPS system offers voltage regulation surge suppression and long lasting expandable battery support for personal computers internetworking equipment and other sensitive electronics. Internal UPS batteries support entry level PC systems for up to 75 minutes during power failures so that connected equipment can be shut down without data loss. Automatic Voltage Regulation (AVR) circuits regulate brownouts as low as 75 and overvoltages up to 147 volts back to usable 120V levels without using battery power. Offers complete desktop power protection in an attractive black tower configuration. Includes 6 battery supported outlets for computer monitor and vital system peripherals plus 2 additional surge suppression only outlets for printers and other system accessories not requiring battery support. USB port enables optional unattended system shutdown without data loss in the case of extended power failure (USB cable included). Built-in data line suppression offers protection for equipment with single line TEL/DSL or network Ethernet connection. Built-in audible alarm and 5 front panel LEDs indicate status of line power battery power battery low/replace voltage regulation and overload. 1500VA power handling ability supports entry-level PCs network workstations point-of-sale equipment small business phone systems audio/video equipment and home theater systems. Offers 4.5 minutes battery runtime with a full load of 1500VA and 13 minutes with a half load of 750VA. Supports hot-swappable battery replacement via built-in access panel. Extended runtime available with optional BP24V15RT2U BP24V28-2U or BP24V70-3U external battery packs.
- OMNIVS1500XL Uninterruptible Power Supply offers voltage regulation surge suppression and long lasting battery support
- Supports entry level PCs up to 75 minutes during blackouts to enable shutdown without data loss
- Regulates brownouts as low as 75V and overvoltages to 147V back to usable 120V nominal levels without using battery power
- 6 UPS battery supported outlets plus 2 additional surge suppression-only outlets
- USB port and cable enables UPS monitoring and unattended shutdown in the case of extended power failure
- Data line surge suppression protects standard dialup/DSL or Ethernet line connection
- Built-in audible alarm and 5 front panel LEDs indicate status of line power battery power battery low/replace voltage regulation and overload
- 1500VA power handling ability supports a variety of sensitive electronic equipment
- 4.5 minutes full load runtime (1500VA) 13 minutes half load runtime (750VA)
- Runtime is expandable with the addition of external battery packs
- Supports hot swappable battery replacement via built-in access panel
- Optional PDUB15 bypass PDU enables hot-swappable UPS replacement with no disruption to connected equipment
- $200000 Ultimate Lifetime Insurance (U.S. Canada and Puerto Rico only)

Specifications

AC outlet types
NEMA 5�15R
Audible alarms
Y
Automatic Voltage Regulation (AVR)
Y
Battery recharge time
4.5
Cable length
1.8
Cold start
Y
Color of product
Black
Cooling type
Active
Depth
190
Efficiency
90
EMI/RFI noise filtering
Y
Form factor
Tower
Height
298
Hot-swap battery
Y
Input operation voltage (max)
147
Input operation voltage (min)
75
LED indicators
Y
Material
Polycarbonate
Maximum current
12
Non-operating relative humidity (non-condensing)
0 - 95
Number of input phases
1
Operating relative humidity range
0 - 95
Operating temperature range (T-T)
0 - 40
Output on PDU sticks
8
Output operation voltage (max)
120
Output power
940
Output power capacity (VA)
1500
Package depth
286
Package height
394
Package weight
13600
Package width
279
Power plug
NEMA 5-15P
Power supply input frequency
60
Storage temperature range (T-T)
-15 - 50
Surge energy rating
690
Typical backup time at full load
4.5
Typical backup time at half load
13
UPS topology
Line-Interactive
USB 2.0 ports quantity
1
Waveform
Sine
Weight
28
Weight
12700
Width
184
