StarTech.com NETRS232 serial server
StarTech.com NETRS232. Cabling technology: 10/100Base-T(X). Input voltage: 100 - 240V. Supported network protocols: VCOM TCP Server TCP Client UDP HTTP DHCP ICMP(PING) Static IP ARP. Dimensions (WxDxH): 2.17 x 3.74 x 0.866" (55 x 95 x 22 mm) Weight: 2.22 oz (63g) Package width: 6.1" (15.5 cm). Certification: UL RoHS CE. FCC
| $125.31 |
Manufacturer:
STARTECH.COM
Item:
NETRS232
Our Part #
NETRS232
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $6.27 |
$125.31EA
Availability
In Stock
Product description
Connect configure and manage a remote RS-232 serial device over an IP network
The NETRS232 Serial Device Server lets you remotely access and manage an RS232 serial device over a local or wide area network (LAN/WAN) giving you a simple and cost-effective serial-over-IP control solution.
For installation flexibility across a variety of locations or environments you can power the serial device server using either a 12V DC power adapter (included) or through the integrated 10~30V DC terminal block. Plus the device server is DIN rail mountable for out-of-the-way installations. To help ensure seamless performance and prevent possible damage to the server and connected devices the serial device server offers 15KV ESD (Electrostatic Discharge) protection.
This highly-customizable device server is easy to configure to suit your application with versatile browser-based or Virtual Com port software configuration and integrates support for VCOM TCP Server/Client UDP HTTP DHCP ICMP(PING) Static IP and ARP protocols while supporting baud rates up to 230.4 Kbps and is compliant with IEEE 802.3 IEEE 802.3u standards.
Backed by a 2-year StarTech.com warranty and free lifetime technical support.
The StarTech.com Advantage
- Mount on DIN rails with the attached mounting bracket
- Flexible power input via 10~30V DC terminal block adapter or the included DC power adapter
- Convenient configuration via software utility or web browser
Specifications
Baud rate
230.4
Cabling technology
10/100Base-T(X)
Certification
UL RoHS CE. FCC
Dimensions (WxDxH)
55 x 95 x 22
Ethernet LAN (RJ-45) ports quantity
1
Input voltage
100 - 240
LED indicators
Y
Link/Act LED
Y
Linux operating systems supported
Y
Network standard
IEEE 802.3 IEEE 802.3u
Operating relative humidity range
0 - 90
Operating temperature range (T-T)
0 - 60
Package height
80
Package width
155
Power LED
Y
Serial interface type
RS-232
Serial ports quantity
1
Storage temperature range (T-T)
-10 - 70
Supported network protocols
VCOM TCP Server TCP Client UDP HTTP DHCP ICMP(PING) Static IP ARP
Surge protection
15
Weight
63
Wi-Fi
N
Windows operating systems supported
Y
