Cisco Nexus 5548
Cisco Nexus 5548. Switch layer: L2 Switch type: Managed. Basic switching RJ-45 Ethernet ports quantity: 48 1 48 Console port: RJ-45 Copper ethernet cabling technology: 1000BASE-T 100BASE-TX 10BASE-T. MAC address table: 32000 entries Maximum data transfer rate: 960 Gbit/s. Certification: RoHS. Power consumption (typical): 390W Input voltage: 100 - 240V
| $24,417.65 |
Manufacturer:
CISCO
Item:
N5K-C5548UP-FA
Our Part #
N5K-C5548UP-FA
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $1,220.88 |
$24,417.65EA
Availability
In Stock
Product description
The Cisco Nexus 5500 platform is equipped with expansion modules that can be used to increase the number of 10 Gigabit Ethernet and FCoE ports or to connect to Fibre Channel SANs with 8/4/2/1-Gbps Fibre Channel switch ports or both.
The Cisco Nexus 5548P and 5548UP supports one expansion module and 5596UP supports three expansion modules from the following offerings
- Ethernet module that provides sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface
- Fibre Channel plus Ethernet module that provides eight 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface and eight ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+/SFP interface
- A unified port module that provides up to sixteen 1/10 Gigabit Ethernet and FCoE ports using the SFP+ interface or up to sixteen ports of 8/4/2/1-Gbps native Fibre Channel connectivity using the SFP+ and SFP interface. The use of 1/10 Gigabit Ethernet or 8/4/2/1-Gbps Fibre Channel on a port is mutually exclusive but selectable for any of the 16 physical ports per module.
Specifications
10G support
Y
Basic switching RJ-45 Ethernet ports quantity
48 1 48
Certification
RoHS
Console port
RJ-45
Copper ethernet cabling technology
1000BASE-T 100BASE-TX 10BASE-T
Dimensions (WxDxH)
439 x 749 x 44
Input frequency
50/60
Input voltage
100 - 240
Installed ports
32
Jumbo Frames support
Y
MAC address table
32000
Maximum data transfer rate
960
Network standard
IEEE 802.1D IEEE 802.1p IEEE 802.1Q IEEE 802.1s IEEE 802.1w IEEE 802.3 IEEE 802.3ad IEEE 802.3ae IEEE 802.3x
Non-operating altitude
0 - 300
Operating relative humidity range
0 - 40
Power consumption (typical)
390
SFP/SFP+ ports quantity
32
SSH/SSL support
Y
Storage relative humidity range
5 - 95
Storage temperature range (T-T)
-40 - 70
Switch layer
L2
Switch Type
Managed
Weight
14.51
