StarTech.com IES61002POE Network Switch
StarTech.com IES61002POE. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Network standard: IEEE 802.1af IEEE 802.3 IEEE 802.3ab IEEE 802.3at IEEE 802.3u IEEE 802.3x IEEE 802.3z. Switching capacity: 2 Gbit/s. Color of product: Black LED indicators: Activity Link PoE Power
| $522.85 |
Manufacturer:
STARTECH.COM
Item:
IES61002POE
Our Part #
IES61002POE
Condition
New
Extended Warrenty
| 1 Year Extended Warrenty | $26.14 |
$522.85EA
Availability
In Stock
Product description
Connect Gigabit Ethernet data and power to 4 PoE-enabled devices with 2 additional GbE ports and redundant power input
The IES61002POE 6-Port Industrial PoE+ switch lets you connect Gigabit Ethernet data and power to four PoE-enabled devices with two additional GbE ports.
Fully compliant with IEEE 802.3at / 802.3af the industrial Ethernet switch offers up to 30 Watts output per port through the four PoE+ / PSE ports while all six shielded RJ45 ports support auto-negotiation of speed and duplex for 10/100/1000Mbps Ethernet networks.
Providing seamless power failover in the event of power dips or failures the switch features redundant 20-57V DC (nominal 24/48V DC) terminal block power inputs. When used with multiple power sources the switch supports alarm relay contacts which can be wired to your existing alarm circuit to give you instant notice when a power disruption occurs.
The switch also features an internal DC-DC converter with voltage regulation which provides the PoE injector with high voltage output from a low voltage input (
To ensure dependable performance in harsh environments this power over Ethernet switch features an extended operating temperature range (-40�C to 75�C) a rugged IP-30 rated case design and includes both DIN-Rail and wall-mount brackets for flexible installation options.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Power devices through PoE where electrical outlets are not available
- Operate under harsh industrial conditions with an extended temperature range and IP-30 rated enclosure
- Maintain device operation during power disruptions with redundant power inputs
Specifications
10G support
N
Basic switching RJ-45 Ethernet ports quantity
6
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Color of product
Black
DC-in jack
Y
Depth
63
Full duplex
Y
Height
135
LED indicators
Activity Link PoE Power
Manual
Y
Mean time between failures (MTBF)
296517
Network standard
IEEE 802.1af IEEE 802.3 IEEE 802.3ab IEEE 802.3at IEEE 802.3u IEEE 802.3x IEEE 802.3z
Operating relative humidity range
5 - 95
Operating temperature range (T-T)
-40 - 75
Package depth
235
Package height
75
Package weight
1100
Package width
185
Power consumption (typical)
143
Power over Ethernet (PoE) support
Y
Storage temperature range (T-T)
-40 - 85
Switch Type
Unmanaged
Switching capacity
2
Total Power over Ethernet (PoE) budget
120
Weight
831
Width
106
